2.0 SERVICE CONNECTIONS
Unless otherwise specified, Field Wire Electrical Connection to be 120
Volts, 60 Hz. single phase with grounding wire. Unit furnished with 8’ cord
and 3 prong plug.Total max amps 2.0.
GAS CONNECTION: Supply gas through 3/4” pipe.
NATURAL 6”-14” W.C. (152mm - 355mm W.C.)
PROPANE 12” - 14” W.C. (305mm - 355 mm W.C.)
Contact manufacturer for installation over 2,000 ft. elevation.
H
C
COLD WATER - 3/8” O.D. tubing to faucet (optional)
HOT WATER - 3/8” O.D. tubing to faucet (optional)
SAFTEY RELIEF
VALVE AIR VENT
25.
388 [
645]
3 [76]
H C
4.75 [121]
23.
75 [
603] 1.50 [
38]
5.
38 [
137]
Ш20 [508]
Ш16.75
[425] I.D.
30 [762]
15.
88 [
403]
6 [
752] 23.
88 [
607]
32.
88 [
835]
55.
75 [
1416]
OPTIONAL FAUCET
POUR PATH
11.25 [285]
15 [381]
17.25 [483] 7.75 [197]
5.
5 [
140]
FLANGED FOOT DETAIL
4 EQUALLY SPACED
Ø7/16” [11MM] HOLES
ON 3 [76] B.C.
CLEARANCES:
SIDES = 0 [0]
BACK = 6 [152]
FOR USE ON NON-COMBUSTIBLE FLOORS ONLY
