AT-3726XL, AT-3716XL, and AT-3714FXL Installation Guide
2-9
Media Dependent Adapters
Four types of MDAs can be installed in the switches: either the
AT-A10 (RJ45), the AT-A11 (Fiber/SC), the AT-A20 (Fiber/MT) or the
AT-A21 (Fiber/VF).
Figure 2-3 Media Dependent Adapter Faceplates
Verifying Package
Contents
Make sure that you have received the following items:
# AT-A10, AT-A11, AT-A20 or AT-A21 adapter
# 3 flathead Phillips screws
# AT-A10, AT-A11, AT-A20 and AT-A21 Quick Install Guide
# Warranty Card
AT-A11
100BASE-FX/SC
RX TX
AT-A10
100BASE-TX
X
AT-A21
100BASE-FX/VF
AT-A20
100BASE-FX/MT
X X
AT-A10 (TX) AT-A11 (FX/SC)
AT-A20 (MT-RJ) AT-A21 (VF-45)
