Physical and Layer 2 Interfaces
73
Software Release 2.5.2
C613-02034-00 REV A
Default Setup
The standard LAPD configurations are shown in Table 8 on page 73 (Basic Rate
Interfaces) and Table 9 on page 73 (Primary Rate Interfaces). These settings suit
many situations. However, you can modify these settings as required to suit
other network situations (see the Integrated Services Digital Network (ISDN)
chapter, AR400 Series Router Software Reference).
Testing the BRI or PRI PIC
To test the ISDN PRI, BRI (U), or BRI (S/T) PIC you need to configure a routing
protocol such as IP or IPX to use ISDN.
For more information about configuring ISDN calls and routing protocols, see
“Configuring ISDN (AR410 only)” on page 74, “Configuring an IP Network” on
page 83, and “Configuring a Novell IPX Network” on page 95.
Table 8: Standard LAPD configuration for an ISDN Basic Rate Interface.
Mode
Auto
Debug Off
TEI
Provided by the network
T, N and k values (for each SAPI):
SAPI
Layer 3
T200
T201
T202
T203
N200 N201 N202 k
0
Q.931 Call Control
10
10
20
100
3
260
3
1
1
Q.931 Packet Mode
10
10
20
100
3
260
3
3
16
X.25 Packet Mode
10
10
20
100
3
1024
3
3
63
LAPD Management
10
10
20
100
3
260
3
1
Table 9: Standard LAPD configuration for an ISDN Primary Rate Interface.
Mode
nonAuto
Debug Off
TEI
0
T, N and k values (for each SAPI):
SAPI
Layer 3
T200
T201
T202
T203
N200 N201 N202 k
0
Q.931 Call Control
10
N/A
N/A
100
3
260
N/A
7
1
Q.931 Packet Mode
10
N/A
N/A
100
3
260
N/A
7
16
X.25 Packet Mode
10
N/A
N/A
100
3
1024
N/A
7
63
LAPD Management
10
N/A
N/A
100
3
260
N/A
7
