100 AR400 Series Router User Guide
Software Release 2.5.2
C613-02034-00 REV A
Figure 12: Example configuration for an IPX dial-on-demand network.
To configure IPX dial-on-demand follow these steps
If the PPP link uses an ISDN call configured as a dial-on-demand link (see
“Configuring ISDN Dial on Demand” on page 79), then you can configure IPX for
IPX dial-on-demand services.
The following steps are required:
1. Clear the previous IPX configuration.
2. Enable IPX.
3. Define the IPX circuits.
4. Save the configuration.
1. Clear previous IPX configuration
To purge the IPX static database to clear an preexisting IPX configuration
enter the command:
PURGE IPX
2. Enable IPX
To enable the IPX routing software on each router, enter the command:
ENABLE IPX
UGIPX2_R
Network = 401
Netware
File Server
Network = 12
Remote PC
Head Office Router Remote Office Router
PPP Data Link
Network = 129
Table 13: Example configuration parameters for IPX dial-on-demand.
Parameter Head Office Router Remote Office Router
Ethernet interface eth0 eth0
Ethernet encapsulation 802.3 802.3
Novell network number for Ethernet 401 12
IPX circuit over Ethernet 1 1
PPP interface ppp0 ppp0
Novell network number for PPP 129 129
IPX circuit over PPP 2 2
