Getting Started with the Graphical User Interface (GUI) 27
Software Release 2.5.2
C613-02034-00 REV A
Figure 2: Connecting a PC directly to the router.
2. Enable IP, using the command:
ENABLE IP
3. Assign the vlan1 interface an IP address in the same subnet as the PC, using
the command:
ADD IP INTERFACE=vlan1 IP=ipaddress MASK=mask
To access the GUI from a PC in your LAN, in the same subnet as the router
(Figure 3 on page 27):
1. Plug the router in and access its command line interface.
Use a patch cable to connect any one of the router’s switch ports to a device
on your LAN (for example, a hub, router or switch).
Access the CLI from a PC that is connected to this device, as described in
“Connecting a Terminal or PC” on page 14.
Figure 3: Connecting your LAN to the router.
2. Enable IP, using the command:
ENABLE IP
Hub or
switch
