Technical Specifications
18
Electrical Rating
Input Supply Voltage 3.3V DC
Minimum Current Rating 1.5A
Maximum Power
Consumption 6W
Fiber Optic Port Specifications
The following tables list the specifications for the 100Base-FX fiber optic port.
Table 5 Fiber Optic Transmitter
Model
Fiber
Type
1
1. MMF = Multimode Fiber / SMF = Single-mode Fiber.
Fiber
Optic
Diameter
Optical
Frequency
Launch Power 2
2. The launch power is measured at one meter from the transmitter.
Maximum Average Minimum
AT-FS211
AT-FS212
AT-FS214
AT-FS215
AT-FS216
AT-FS217 MMF 50/125 1310 nm -14.0 -20.3 -22.5
MMF 62.5/125 1310 nm -14.0 -16.8 -19.0
AT-FS212/1 SMF 9/125 1310 nm -8.0 -11.5 -15.0
AT-FS212/2 SMF 9/125 1310 nm 0.0 -3.0 -5.0
AT-FS212/3 SMF 9/125 1310 nm 0.0 -2.0 -4.0
AT-FS212/4
3
3. The cable must be non-dispersion-shifted, dispersion-shifted, or non-zero dispersion-shifted single-mode fiber
optic cable.
SMF 9/125 1550 nm 0.0 -1.5 -3.0
