AT-MC1x Series Installation Guide
3
Key Features
The media converters have the following key features:
q
LEDs for unit and port status
q
Full- or half-duplex mode operation (except AT-MC15)
q
Half-duplex mode operation (AT-MC15 only)
q
MissingLink

notifies end-nodes of link failures (fiber models only)
q
Link Test feature performs a link test on the media converter’s fiber
port
q
MDI/MDI-X switch that eliminates the need for a crossover cable
q
Internal termination on the BNC port (AT-MC15 only)
q
External AC/DC power adapter
q
Standard, compact size for desktop use or in an AT-MCR12 rackmount
chassis
Status LEDs
Table 3 lists the status LEDs for the AT-MC1x Series Media Converters.
Table 3 Status LEDs for the Media Converters
LED Color Description
All Models
PWR Green Power is applied to the media converter.
LNK Green A link has been established on the port.
REC Green Data is being received.
AT-MC13, AT-MC14 and AT-MC16 only
NML Green
OFF
The MissingLink feature is enabled and the media converter is
functioning in normal operating mode.
The MissingLink feature is disabled and the media converter is
performing a link test.
