Installation
12
Hub to MAU Wiring. The most typical UTP cable for the AT-MR415T/
AT-MR815T Micro Repeater will be UTP Hub-to-UTP transceiver Data
Terminal Equipment (DTE).
To configure your own cables, see Appendix A, “Technical Specifications” on
page 23.
Quick Installation
If you are experienced with electronic networks in general and repeaters in
particular, use the following procedure. If you are not certain, or would like to
review the installation process, read this list and go on to the next section.
1. Carefully unpack your AT-MR415T/AT-MR815T Micro Repeater. Keep the
packing materials until you have successfully installed the product.
2. Place the AT-MR415T/AT-MR815T Micro Repeater in a location with
adequate ventilation and power receptacles.
3. Attach the power cable from your AC adapter into the DC-IN port which is
located on the back panel.
Note
Power to the hub must be sourced only from the direct plug in type
approved adapter rated 7.5Vdc, 500mA.
4. Apply power to the AC adapter by plugging it into an appropriate AC
source.
5. Attach your 10Base-T UTP cables, with RJ-45 connectors attached, to the
10Base-T ports. If the UPLINK port is not used for cascading, you may
connect a standard 10Base-T cable to port 4/8.
Note
Do not connect standard telephone line into the signal connector.
