1
AT-MC104XL and AT-MC104LH
Media Converters
The AT-MC104XL and AT-MC104LH (Long Haul) are 100Base-FX media
converters that convert 100Base-FX multimode (MMF) to 100Base-FX single
mode (SMF). The converters feature SC connectors and come with an external
12 V DC power adapter to supply power. See Figure 1 and Figure 2.
Figure 1 AT-MC104XL Media Converter
Figure 2 AT-MC104LH Media Converter
REC
SINGLE MODE MULTI MODE
LNK
REC
LNK
PWR
NML
TX RX
MC104XL SINGLE MODE / MULTI MODE FIBER FAST ETHERNET MEDIA CONVERTER
NML
LNK TST
CLASS 1
LASER LIGHT
DO NOT STARE
INTO BEAM
100Base-FX TX RX 100Base-FX
REC
SINGLE MODE MULTI MODE
LNK
REC
LNK
PWR
NML
TX RX
MC104LH SINGLE MODE LONG HAUL / MULTI MODE FIBER FAST ETHERNET MEDIA CONVERTER
NML
LNK TST
CLASS 1
LASER LIGHT
DO NOT STARE
INTO BEAM
100Base-FX TX RX 100Base-FX
