8
Troubleshooting
To troubleshoot your media converter, perform the following:
1. Set the unit in the Link Test mode.
2. End stations used with the media converter must operate in the same
duplex mode (either both full-duplex or both half-duplex).
3. Verify that proper fiber cable is being used (See Table 3 on page 9).
4. Verify that the near end node transmitter (TX) is connected to the far end
node receiver (RX) and vice versa on each fiber segment.
Technical Specifications
Table 2 lists the media converter technical specifications.
Table 2 Technical Specifications for AT-MC104XL and AT-MC104LH
Specifications
Dimensions 10.5 cm W x 9.5 cm D x 2.5 cm H
(4.125 in x 3.75 in D x 1.0 in H)
Max. Operating Temperature 0
o
C to 40
o
C (32
o
F to 104
o
F)
Max. Storage Temperature -20
o
C to 80
o
C (-4
o
F to 176
o
F)
Operating altitude up to 3,048 m (10,000 ft)
Humidity 5% to 80% (non-condensing)
EMI/RFI meets FCC Class A, EN55022 Class A
Safety EN60950, UL 1950, CSA 950
EN60825
Immunity EN50082-1 1997 Immunity Standard
Power:
Input supply voltage
Max. current
Power consumption
12 V DC +/-5%
500 mA
6W
