Note - The current firmware version does not allow the Port VLAN Tag Priority parameter to
be configured. Attempting to configure this parameter will result in the error message: "The
error occurred with 'Set' operation. Error: bad value."
Note - When connection is established between a twisted pair port that is configured to auto-
negotiate and a port on another device that is configured to operate at 10/100Mbps full/half
duplex, expect the link to drop when the twisted pair port's speed and mode is changed to
match the speed and mode of the port on the other device.
Note - Valid MIB Set values for the Port State parameter are 'enabled' and 'disabled'.
Attempting to set this parameter to any other value will result in the error message: "The
error occurred with 'Set' operation. Error: bad value."
Spanning Tree Info
Displays the port's spanning tree parameters.
Enable
Enables the port.
Disable
Disables the port.
QoS
Displays QoS parameters and allows enabling of QoS status and setting priority queue.
Port Mirroring
Displays port mirroring parameters and allows configuration of port mirroring state, source
and destination.
IGMP Snooping
Displays the current state of IGMP Snooping and allows reconfiguration.
AT-9410GB
