• When the Port Speed and Mode parameter of the AT-A46 expansion module port is set to
"auto 10/100Mbps" and the port is connected to a 10/100Mbps full-duplex port on another
device, its corresponding Duplex LED on the device image turns orange instead of green.
• The Spanning Tree Protocol (STP) does not work for the AT-A46 expansion module when it
is installed on an AT-8016F/ST device. As a result, the Port State parameter of the AT-A46
expansion module port will never be set to 'blocking' and the port image will never turn
yellow.
• Connection between an AT-A47 expansion module port that is configured to operate at
1Gbps full duplex and a port on another device can only be established if the port on the
other device is configured to auto-negotiate.
• For the AT-A47 expansion module, AT-View Plus Device Manager will only display the
AT-A45/AT-A47/AT-STACKM shared GIF image if a GBIC module is present in the GBIC
slot.
• By default, the Port Speed and Mode parameter of the AT-A47 expansion module port is set
to 'auto sense'. From this mode, the Port Speed and Mode can only be changed to '1Gbps full-
duplex'. However, once set to '1Gbps full-duplex', it can no longer be set to 'auto sense'.
• The Port Speed and Mode parameter of the AT-STACKM expansion module cannot be
modified. It is fixed at '1Gbps full-duplex'.
AT-8000 Series
