AT-ARW256E Quick Installation Guide
Chapter 2: Configuring Your Ethernet Network
Card / Installing Your USB Device
If your computer/notebook is connected to the Ethernet Port of the Wireless ADSL
Router, proceed with
chapter 2.1 . If your computer/notebook is connected to the
USB Port of the Wireless ADSL Router, proceed with chapter 2.2 . If your
computers/notebooks are connected to both the Ethernet Port and USB Port of your
Wireless ADSL Router, please proceed with both
chapter 2.1 and 2.2 !
2.1 Configuring Your Ethernet Network Card
1. Proceed with this section ONLY if your computer/notebook is connected to
the Ethernet Port of your Wireless ADSL Router.
2. The following illustrated screen shots serve only as examples. For any
dissimilarities, please follow closely the instructions prompted on your
Computer.
2.1.1 For Windows® 98 Second Edition / Windows® Me
i
From your Windows desktop, right-click on the Network Neighborhood icon. Select
Properties .
ii ii From the Configuration tab, select TCP/IP-> xxx where xxx refers to the model of
your Ethernet Card that is connected to your Wireless ADSL Router.
Click
Properties .
(This screen shot uses 3Com EtherLink Ethernet card model as an example).
Page 9 of 32
