AT-ARW256E Quick Installation Guide
iii Click the IP Address tab.
Click the option Obtain an IP address automatically and click OK to save the settings.
Ensure that your Wireless ADSL Router is powered on. Restart your system.
Proceed to
Chapter 3 .
2.1.2 For Windows® 2000 / Windows® XP
i Windows® 2000:
a) From your Windows desktop, right-click on the icon My Network Places and
select Properties .
b) At
the Network and Dial-up Connections window, right-click on the Local Area
Connection icon and select Properties .
Windows® XP:
(Instructions are based on default Start menu option)
a)
From your Windows desktop, click Start > All Programs > Accessories >
Communications > Network Connections .
b)
Right-click on the Local Area Connection icon that reflects the model of your
Ethernet Card that is connected to your Wireless ADSL Router and click
Properties .
ii
Ensure that the field Connect Using indicates the model of your Ethernet Card that is
connected to your Wireless ADSL Router.
(This is important especially if you have more than one Local Area Connection icons displayed at the
Network and Dial-up Connections / Network Connections window. Ensure that you have selected the
correct one.)
Select
Internet Protocol (TCP/IP) and click Properties .
(This screen shot uses 3Com EtherLink Ethernet card model as an example).
Page 10 of 32
