AT-ARW256E Quick Installation Guide
xviii
Upon successfully connection, the Dialup application will be minimize and an
icon
will be created at the right-hand bottom of the task bar. Your home webpage will be
launched automatically and the info screen displayed below will minimize
automatically.
This icon symbolized the Wireless ADSL Router is connected to the Internet
This icon symbolized that the Wireless ADSL Router is not connected to the
Internet
Important:
Router Default Setting
Firmware version
43.12.1
Protocol PPPoE
VPI / VCI
0 / 35
DSL Configuration
Multimode
LAN IP Address
192.168.1.1
Netmask 255.255.255.0
DHCP Server
Enable
DHCP Range
192.168.1.2 to 192.168.1.254
NAT Enable
Remark : Currently Self Installation Wizard from the Installation CD has its default at PPPoE
and VPI/VCI is 0/35. To change the VPI/VCI setting, please follow below steps:
r address bar.
ii)
At the top menu, click on the “Basic” button.
iii)
On the left side menu, click on “Quick Start: link.
iv)
Click on Protocol dropdown list to select your desired protocol.
v)
Change your VPI and VCI.
vi)
Click on “Connect” to apply the changes and try connecting to the Internet.
