Document 50934 Rev B 5/15/00 PN 50934:B 40
The reporting structure for the Ademco Contact ID format is as follows:
SSSS 18 QXYZ GG CCC
where
SSSS = Four digit Subscriber ID (addresses 17 - 20 and
43 - 46)
18 = Identifies transmission as Contact ID to the
receiver at the Central Station
Q = Event Qualifier
1 = New Event
2 = New Restore
XYZ = Event code (shown in Tables 3-4 and 3-7)
GG = Group number or Loop number
CCC = Device or Zone number
For general reports (alarm, trouble and supervisory), the GG and CCC fields
are transmitted as 00 and 000 unless changes to addresses 64-65 and 66-68
are made.
64 - 65 = Loop number (GG), (factory default is 00)
66 - 68 = Device/Zone number (CCC) for General Alarm,
Fault or Supervisory messages (factory default is 000).
A typical printout of alarm and trouble reports in the Ademco Contact ID
Reporting Structure follows:
Time Date SSSS QXYZ GG CCCC 4
11:28 03/25 11 7777 E110 00 C000 - general alarm
11:28 03/25 11 7777 E111 00 C046 - alarm SD46
11:28 03/25 11 7777 E300 00 C000 - general trouble
11:28 03/25 11 7777 E380 00 C046 - trouble SD46
11:28 03/25 11 7777 R110 00 C000 - general alarm restore
11:28 03/25 11 7777 R111 00 C046 - alarm SD46 restore
11:28 03/25 11 7777 R300 00 C000 - general trbl restore
11:28 03/25 11 7777 R380 00 C046 - trouble SD46 restore
Table 5-3: Ademco Contact ID Reporting Structure
Notes:
1) In the sample report, SD46 refers to smoke detector at address 46 or
on zone 46.
2) 18, which is used in the reporting structure to identify the transmission
as Contact ID, is not printed out in the alarm and trouble report.
3) Q, which is the Event Qualifier for the reporting structure, is printed out
in the report as an E for New Event or R for New Restore.
4) CCCC, the first C is not transmitted by the ADT-UDACT but is printed
by the Central Station Receiver printer output.
Rcvr/
Line ID
