Document 50934 Rev B 5/15/00 PN 50934:B 26
Address Description Setting 1 Group # 6 Sensor No.
69 - 71 Primary # General Alarm Code 110 00 000 2
72 - 74 Primary # Zone/Point Alarm Code 5 110 4 00 Note 3
75 - 77 Primary # General Supervisory Code 200 00 000 2
78 - 80 Primary # Zone/Point Supervisory Code 5 200 00 Note 3
81 - 83 Primary # General Fault Code 300 00
84 - 86 Primary # AC Fault Code 301 00
87 - 89 Primary # Zone/Point Fault Code 5 380 00 Note 3
90 - 92 Primary # Low Battery Fault Code 302 00
93 - 95 Primary # Telco Primary Line Fault Code 351 00
96 - 98 Primary # Telco Secondary Line Fault Code 352 00
99 - 101 Primary # NAC Fault Code 321 00
102 - 104 Primary # Comm. Trouble Primary # Code 354 00
105 - 107 Primary # Comm. Trouble Secondary # Code 354 00
108 - 110 Primary # 485 Comm. Trouble Code 300 00
111 - 113 Primary # System Off Normal Code 308 00
114 - 116 Primary # ADT-UDACT Off Normal Code 350 00
117 - 119 Primary# System 24 Hour Test 602 00
120 - 122 Primary # System 24 Hour Test w/active event 608 00
123 - 125 Primary # Manual Test Message 601 00
Notes:
1) Note: Zero entries prevent the transmission of the report to the Central Station.
2) Refer to Contact ID program locations 64 - 68.
3) The identification of the zone/device number is automatically transmitted by the ADT-UDACT and is
added to the main event code. See Table 5-3 for more information.
4) For control panels Unimode 2020/1010, ADT-MNNA, and the Unimode 300/400 the factory default
event code is 110 and reprogrammable. The Unimode 400 is unique in point reporting mode in that
only the control module report codes are programmable. The factory setting of report code 111 is
fixed for addressable smoke detectors and cannot be changed.
5) The Group # is automatically incremented for Unimode 2020/1010 and ADT-MNNA applications.
Ademco Contact ID Format
If 'E' is entered for address 16, the following data is automatically programmed for the Primary
phone number event codes.
Enter a '000' for the data setting to disable the report.
Table 3-4: Ademco Contact ID, Primary Number
