Document 50934 Rev B 5/15/00 PN 50934:B 29
Ademco Contact ID Format
If 'E' is entered for address 42, the following data is automatically programmed for the Secondary
phone number event codes.
Enter a '000' for the data setting to disable the report.
Address Description Setting 1 Group # 6 Sensor No.
139 - 141 Secondary # General Alarm Code 110 00 000 2
142 - 144 Secondary # Zone/Point Alarm Code 110 4 00 Note 3
145 - 147 Secondary # General Supervisory Code 200 00 000 2
148 - 150 Secondary # Zone/Point Supervisory Code 200 00 Note 3
151 - 153 Secondary # General Fault Code 300 00
154 - 156 Secondary # AC Fault Code 301 00
157 - 159 Secondary # Zone/Point Fault Code 380 00 Note 3
160 - 162 Secondary # Low Battery Fault Code 302 00
163 - 165 Secondary # Telco Primary Line Fault Code 351 00
166 - 168 Secondary # Telco Secondary Line Fault Code 352 00
169 - 171 Secondary # NAC Fault Code 321 00
172 - 174 Secondary # Comm. Trouble Primary # Code 354 00
175 - 177 Secondary # Comm. Trouble Secondary # Code 354 00
178 - 180 Secondary # 485 Comm. Trouble Code 300 00
181 - 183 Secondary # System Off Normal Code 308 00
184 - 186 Secondary # ADT-UDACT Off Normal Code 350 00
187 - 189 Secondary # System 24 Hour Test 602 00
190 - 192 Secondary # System 24 Hour Test w/active event 608 00
193 - 195 Secondary # Manual Test Message 601 00
Notes:
1) Note: Zero entries prevent the transmission of the report to the Central Station.
2) Refer to Contact ID program locations 64 - 68.
3) The identification of the zone/device number is automatically transmitted by the ADT-UDACT and is
added to the main event code. See Table 5-3 for more information.
4) For control panels Unimode 2020/1010, ADT-MNNA, and Unimode 300/400 the factory default event
code is 110 and reprogrammable. The Unimode 300 and Unimode 400 are unique in point reporting
mode in that only the control module report codes are programmable. The factory setting of report
code 111 is fixed for addressable smoke detectors and cannot be changed.
5) The Group # is automatically incremented for Unimode 2020/1010 and ADT-MNNA applications.
Table 3-7: Ademco Contact ID, Secondary Number
