Programming the Real-Time Clock
Entering an address greater than 209 will cause a display of the current time. On
initial power up, the clock will start running from the factory setting of 00:01
(military time). The far left digit will be flashing, indicating that this is the first digit
to be programmed.
Hours/Minutes
Select a digit then press [ENTER/STORE]. The digit 2nd from the left will start
flashing. Select a digit then press [ENTER/STORE]. Hours setting is complete.
With the digit 2nd from the right flashing, select a digit then press [ENTER/
STORE]. The digit on the far right will start flashing. Select a digit then press
[ENTER/STORE]. Minutes setting is complete.
End Programming
Exit Programming Mode by pressing MODE, followed by the 4-digit code
corresponding to an alternate mode of operation, then press [ENTER/STORE].
During Program Mode, if no key is pressed within 10 minutes, the ADT-UDACT will
revert to normal mode.
Table 3-2: Event Codes, Primary Number
3+1, 4+1 Express and 4+1 Standard Formats
If '0, 2, 4, 6 or 8' are entered for
address 16, the following data is automatically programmed for the Primary phone
number event codes. Enter a '0' for the data setting to disable the report. These
formats do not support zone/point programming. For zone/point reporting, refer to
Contact ID.
Address
Description
Setting
69
Primary # General Alarm Code
1
70
Primary # Zone/Point Alarm Code
0
71
Primary # General Supervisory Code
8
72
Primary # Zone/Point Supervisory Code
0
73
Primary # General Fault Code
F
74
Primary # AC Fault Code
F
75
Primary # Zone/Point Fault Code
0
76
Primary # Low Battery Fault Code
F
77
Primary # Telco Primary Line Fault Code
F
78
Primary # Telco Secondary Line Fault Code
F
79
Primary # NAC Fault Code
F
80
Primary # Comm. Trouble Primary # Code
F
81
Primary # Comm. Trouble Secondary # Code
F
82
Primary # 485 Comm. Trouble Code
F
83
Primary # System Off Normal Code
F
84
Primary # ADT-UDACT Off Normal Code
F
85
Primary # General Alarm Restore Code
E
86
Primary # Zone/Point Alarm Restore Code
0
87
Primary # General Supervisory Restore Code
E
88
Primary # Zone/Point Supervisory Restore Code
0
89
Primary # General Fault Restore Code
E
90
Primary # AC Fault Restore Code
E
91
Primary # Zone/ Point Fault Restore Code
0
92
Primary # Low Battery Fault Restore Code
E
93
Primary # Telco Primary Line Fault Restore Code
E
94
Primary # Telco Secondary Line Fault Restore Code
E
95
Primary # NAC Fault Restore Code
E
96
Primary # Comm.Trouble Primary Number Restore Code
E
97
Primary # Comm. Trouble Secondary Number Restore Code E
98
Primary # 485 Comm. Trouble Restore Code
E
99
Primary # System Off Normal Restore Code
E
100
Primary # ADT-UDACT Off Normal Restore Code
E
101
Primary # System 24 Hour Test
9
102
Primary # System 24 Hour Test w/active event
F
103
Primary # Manual Test
9
Note:
Zero entries prevent the transmission of the report to the Central Station.
