Document 50934 Rev B 5/15/00 PN 50934:B 38
Table 5-1 shows the data reporting structure for each of the pulsed formats as well as
the Ademco Express formats. Ademco Express formats allow a typical data message
to be transmitted to the Central Station in under 5 seconds. Pulsed formats typically
require 15 to 20 seconds in comparison. Table 5-2 defines each letter code used in
Table 5-1. Table 5-3 describes the data reporting structure used for Ademco Contact
ID format. Do not select any of the pulsed or Ademco Express Formats if
identification of the specific zone or point is desired. Use Ademco Contact ID for
specific zone or point identification.
5.0 Reporting Formats
Format #
0,2, 4, 6, 8
Format #
1,A, C
Report 3+1/4+1/Standard
4+1 Express
4+2/Standard
4+2 Express
Alarm SSS(S) A SSSS AA2
Alarm Restore SSS(S) RA SSSS RARA2
Zone Trouble
(Zone Open)
SSS(S) RTZ SSSS TZTZ2
Zone Trouble Restore SSS(S) RTZ SSSS RTZRTZ2
System Trouble SSS(S) TS SSSS TSTS2
System Trouble Restore SSS(S) RTS SSSS RTSRTS2
Low Battery SSS(S) L SSSS LL2
Low Battery Restore SSS(S) RL SSSS RLRL2
AC Loss SSS(S) P SSSS PP2
AC Loss Restore SSS(S) RP SSSS RPRP2
Supervisory Condition SSS(S) V SSSS VV2
Supervisory Condition
Restore
SSS(S) RV SSSS RVRV2
Test Report SSS(S) X SSSS XX2
Abnormal Test Report SSS(S) XA SSSS XAXA2
Refer to Table 5-2 for an explanation of each letter code in Table 5-1.
Refer to Table 6-1 for a list of compatible receivers.
Table 5-1: Data Reporting Structure
