Table 3-5: event codes, secondary number – ADT Security Services ADT-UDACT User Manual
Page 27
Document 50934 Rev B 5/15/00 PN 50934:B
27
139
Secondary # General Alarm Code
1
140
Secondary # Zone/Point Alarm Code
0
141
Secondary # General Supervisory Code
8
142
Secondary # Zone/Point Supervisory Code
0
143
Secondary # General Fault Code
F
144
Secondary # AC Fault Code
F
145
Secondary # Zone/Point Fault Code
0
146
Secondary # Low Battery Fault Code
F
147
Secondary # Telco Primary Line Fault Code
F
148
Secondary # Telco Secondary Line Fault Code
F
149
Secondary # NAC Fault Code
F
150
Secondary # Comm. Trouble Primary # Code
F
151
Secondary # Comm. Trouble Secondary # Code
F
152
Secondary # 485 Comm. Trouble Code
F
153
Secondary # System Off Normal Code
F
154
Secondary # ADT-UDACT Off Normal Code
F
155
Secondary # General Alarm Restore Code
E
156
Secondary # Zone/Point Alarm Restore Code
0
157
Secondary # General Supervisory Restore Code
E
158
Secondary # Zone/Point Supervisory Restore Code
0
159
Secondary # General Fault Restore Code
E
160
Secondary # AC Fault Restore Code
E
161
Secondary # Zone/ Point Fault Restore Code
0
162
Secondary # Low Battery Fault Restore Code
E
163
Secondary # Telco Primary Line Fault Restore Code
E
164
Secondary # Telco Secondary Line Fault Restore Code
E
165
Secondary # NAC Fault Restore Code
E
166
Secondary # Comm.Trouble Primary # Restore Code
E
167
Secondary # Comm. Trouble Secondary # Restore Code
E
168
Secondary # 485 Comm. Trouble Restore Code
E
169
Secondary # System Off Normal Restore Code
E
170
Secondary # ADT-UDACT Off Normal Restore Code
E
171
Secondary # System 24 Hour Test
9
172
Secondary # System 24 Hour Test w/active event
F
173
Secondary # Manual Test
9
Note:
Zero entries prevent the transmission of the report to the Central Station.
Table 3-5: Event Codes, Secondary Number
3+1, 4+1 Express or 4+1 Standard Formats
If '0, 2, 4, 6 or 8' are entered for address 42, the following is automatically pro-
grammed for the Secondary phone number event codes. Enter a '0' for the data setting
to disable the report. These formats do not support zone/point programming. For
zone/point reporting, refer to Contact ID.
Address
Description
Setting
