Chapter 1: Overview
22
The port pin assignments can be found in “10/100Base-TX
Port Pinouts” on page 46.
100Base-FX
Fiber Uplink
(WAN) Port
The 100Base-FX fiber uplink (WAN) port on the
AT-iMG606BD Multiservice Gateway features a simplex SC
connector. The gateway port must be connected to a fiber
optic port that is IEEE 802.3ah-compliant and whose
operating specifications are compatible with the fiber optic
port on the gateway.
The fiber optic port is compliant with the 100Base-FX
standard and has a fixed operating speed of 100 Mbps. The
port sends at the wavelength of 1310 nanometers (nm) and
receives at 1550 nm.
The port can operate in either half- or full-duplex mode. The
default setting is full-duplex.
Note
If you are connecting the gateway port to an IEEE
802.3ah-compliant device, you must determine the
duplex mode of the compliant device and set the
duplex mode of the fiber optic port on the gateway
accordingly.
Two kits are available for splicing the fiber optic cable to a
connector: AT-RG012 or AT-RG022 (not supplied). Contact
your Allied Telesyn sales representative for more
information.
The specifications of the fiber optic port can be found in
“100Base-FX Fiber Optic Uplink (WAN) Port” on page 47.
