Chapter 1: Overview
18
Ports
The AT-FS750/48 Fast Ethernet Smart switch features 48 10/100/Base-T
twisted pair ports, two 10/100/1000Base-T twisted pair ports, and two
Gigabit small form-factor pluggable (SFP) ports.
Twisted Pair
Ports
The twisted pair ports feature 8-pin RJ-45 connectors. (For the port
pinouts, refer to “Connectors and Port Pinouts” on page 48.)
Ports 1 through 48 are 10Base-T and 100Base-TX compliant. Ports 49
and 50 are 10Base-T, 100Base-TX, and 1000Base-TX compliant.
The ports are IEEE 802.3u Auto-Negotiation compliant. With Auto-
Negotiation, the switch automatically matches the highest possible
common speed between each switch port and each end node. For
example, if an end node is capable of only 100 Mbps, the switch sets the
port connected to the end node to 100 Mbps.
Each twisted pair port on the switch can operate in either half- or full-
duplex mode. The twisted pair ports are IEEE 802.3u-compliant and Auto-
Negotiate the duplex mode setting.
Note
In order for the switch to set the duplex mode for each port correctly,
the end nodes that you connect to the switch ports should also use
Auto-Negotiation. Otherwise, a duplex mode mismatch can occur,
affecting network performance. For further information, refer to
“Duplex Mode” on page 23.
Each twisted pair port has a maximum operating distance of 100 m
(328 feet).
For 10 Mbps operation, Category 3 or better 100 ohm shielded or
unshielded twisted pair cabling is required. For 100 or 1000 Mbps
operation, Category 5 and Enhanced Category 5 (5E) 100 ohm shielded
or unshielded twisted pair cabling is required.
The twisted pair ports are auto-MDI. They automatically configure
themselves as either MDI or MDI-X. This feature allows you to use either
straight-through or crossover twisted pair cables to connect devices to the
ports.
SFP Ports
The SFP ports, ports 51 and 52, require a 1000SX or 1000LX transceiver.
