Figure 19. tightening the captive screw, Chapter 3: installation 34 – Allied Telesis AT-CV1000 User Manual
Page 34
Chapter 3: Installation
34
7. Use a Phillips screwdriver to tighten the captive screw on the line card,
Figure 19. Tightening the Captive Screw
Note
Always tighten the captive screw to secure the line card to the
chassis.
Refer to the documentation shipped with your line card, or to the
Converteon™ Media Converter Line Cards Reference Guide for cabling
information.
