Configuring a New NMS with New Devices
9-3
AlliedView NMS Installation Guide (Installation Steps - Overview)
8. Use the Discovery Config-
urator to Prepare for the
Discovery Process Select Tools -> Discover Configurator to
bring up the Discovery Configurator Win-
dow. Then follow the tabs:
- General Attributes
- Protocol (always SNMP only)
- Network Discovery (Networks and Masks)
- Node Discovery (optional)
Refer to the Administration Guide, Section 3
The Discovery Configurator
is used to configure the
attributes of the discovery
process, and so it is critical
that these be set up correctly.
9. Use the Security Adminis-
trator Set up NMS users with passwords and scope of
control.
Refer to the Administration Guide, Section 4.
10. Import Link Profiles Create an excel spreadsheet and place it in
\state
.
Refer to the Administration Guide, Section
6.7.3.
Since the physical link configu-
ration for an existing network
can be large and complex, the
Network VLAN Manager can
have an Excel spreadsheet of the
physical links imported. This
will populate the Physical Net-
work map, and any existing Net-
work VLANs that use those
links will be configured.
11. Set Device Attributes Refer to the Administration Guide, Section 5.
12. Configure Applications Refer to the Administration Guide, Sections 5
and 6. With all devices discovered and
being monitored, it is now possi-
ble to configure applications
such as VLANs, HVLANs, and
Network VLANs.
13. Perform a AlliedView
NMS Backup Make a backup of both the AlliedView NMS
file, the database, and devices
Refer to the Administration Guide, Section 3.4,
and Section 5.
Do this on a schedule to ensure
whenever changes due to Steps
11 and 12 are captured and
archived.
TABLE 9-1 Steps for a New AlliedView NMS with New Devices (Continued)
Step Details / Reference Notes
