6-1
AlliedView NMS Installation Guide (Shutting Down the AlliedView NMS)
6. Shutting Down the AlliedView
NMS
6.1 Shutting Down a AlliedView NMS Client
6.1.1 Application Client
For an NMS client running as a user application, to shut down the client, simply select File -> Exit from the
Panel-Specific Menu, or click the X in the upper-right-hand corner of the screen. The Confirmation Message
dialog box will appear. Click Yes in the dialog box to shut down the client.
6.1.2 HTML Client
For a AlliedView NMS HTML client, select File -> Logout from the AlliedView NMS Panel-Specific Menu.
6.2 Shutting Down the AlliedView NMS Server
6.2.1 Windows
To shut down the AlliedView NMS Server on a Windows platform, follow these steps:
1. Select Start -> Programs -> Shutdown Server. The Shutdown Server window will
appear. Do not close this window. Shortly afterwards, the Shutdown AlliedView NMS Server dialog box
will appear.
Note: Click Cancel if you decide not to shut down the server.
2. In the Shutdown AlliedView NMS Server dialog box, enter the root user password in the Password field.
3. If you want to change the shutdown mode:
1. Click Settings. This will display the Mode of Shutdown window.
2. In the Mode of Shutdown window, select the desired mode.
3. Click OK.
4. Click OK. Allow a few seconds for the server to shut down. The Server Shutdown dialog box will appear
when the shutdown is complete.
5. Click OK in the Server Shutdown dialog box.
