Hardware Features
The following sections describe these hardware features of the AT-MC601
and AT-MC602 network extenders:
❑ VDSL Line port
❑ PSTN port
❑ 10/100 Mbps twisted pair Ethernet port
❑ Status LEDs
❑ Management port
❑ Management cable
❑ DC power supply input port
❑ External AC/DC power adapter
VDSL Line Port
The VDSL Line port allows you to connect the AT-MC601 Subscriber unit
to a telephone jack (wall outlet) and the AT-MC602 Provider unit to the
inside phone line at the wiring closet. The two units need to be within
1,200 meters of each other in order for the port to operate properly. The
port transmits voice data at a frequency of 300-3400Hz and Ethernet data
at frequencies of 300 KHz to 8 MHz. This port features an RJ-11
connector.
Table 1 lists the RJ-11 port pinouts and their assignments.
Table 1 VDSL - RJ-11 Port Pinouts
Pin Assignment
1 pass-through 6
2 pass-through 5
3 VDSL and phone ring
4 VDSL and phone tip
5 pass-through 2
6 pass-through 1
