Chapter 9: User Diagnostics
124
C8 DMA Engine Verifies the functionality of the DMA engine
block by performing numerous DMA read and
write operations to various system and
internal memory locations (and byte
boundaries) with varying lengths (from 1 byte
to over 4 KB, crossing the physical page
boundary) and different data patterns
(incremental, fixed, and random). CRC checks
are performed to ensure data integrity. The
DMA write test also verifies that DMA writes
do not corrupt the neighboring host memory.
C9 VPD Exercises the Vital Product Data (VPD)
interface using PCI configuration cycles. You
must program a proper bootcode is
programmed into the non-volatile memory. If
no VPD data is present (that is, the VPD NVM
area is all 0s), the test first initializes the VPD
data area with non-zero data before starting
the test and restores the original data after the
test completes.
C11 FIO Events Verifies that the event bits in the CPU's Fast
IO (FIO) interface are triggering correctly
when a particular chip events occur, such as a
VPD request initiated by the host, an
expansion ROM request initiated by the host,
a timer event generated internally, toggling
any GPIO bits, or accessing NVM.
Group D: Ethernet Traffic Tests
D1 MAC Loopback Enables MAC loopback mode in the adapter
and transmits 5000 Layer 2 packets of various
sizes. As the packets are received by
Broadcom NetXtreme II User Diagnostics,
they are checked for errors. Packets are
returned through the MAC receive path and
never reach the PHY. The adapter should not
be connected to a network.
Table 8. Diagnostic Tests (Continued)
Test
Description
Number Name
