AT-FS716L & AT-FS724L Fast Ethernet Switch Installation Guide
41
Table 3 lists the RJ-45 pin signals when a twisted-pair port is operating in
the MDI configuration.
Table 4 lists the RJ-45 port pin signals when a twisted-pair port is
operating in the MDI-X configuration.
Table 3. MDI Pin Signals (10Base-T or 100Base-TX)
Pin Signal
1 TX+
2 TX-
3 RX+
6 RX-
Table 4. MDI-X Pin Signals (10Base-T or 100Base-TX)
Pin Signal
1 RX+
2 RX-
3 TX+
6 TX-
