Chapter 1: Product Description
12
Key Features
The AT-FS716L and AT-FS724L Fast Ethernet switches have the
following key features:
ˆ 16 each RJ-45 10/100Base-TX ports on the AT-FS716L Switch
ˆ 24 each RJ-45 10/100Base-TX ports on the AT-FS724L Switch
ˆ ecoFriendly power saving features including:
– Auto-power saving mode on a per-port basis when link
is down
– Auto-adjusts port power output based on cable length
when link is up
– Low power mode LED ecoFriendly push button
– Highly efficient internal Power supply
ˆ Quiet, “fanless” operation
ˆ Auto MDI/MDI-X on all ports
ˆ Auto-Negotiation on all ports (IEEE 802.3u-compliant)
ˆ Store and forward switching mode
ˆ Backpressure and flow control (IEEE 802.3x-compliant)
ˆ BPDU packet pass through support
ˆ EAPOL packet pass through support
ˆ Storage for up to 8K MAC addresses
ˆ MAC address aging time of 200 to 300 seconds
ˆ Non-blocking full wire speed
ˆ System and port LEDs
ˆ For use on a desktop, wallmount, or rackmount
ˆ RoHS and China RoHS compliant
Standards
The AT-FS716L and AT-FS724L Fast Ethernet switches support the
following standards:
ˆ IEEE 802.3 – 10BASE-T standard
ˆ IEEE 802.3u – 100BASE-TX standard with Auto-negotiation
ˆ IEEE 802.3x – Flow Control, Symmetric and Asymmetric
ˆ IEEE 802.3z - Full Duplex
