AT-2701 Series Fast Ethernet Adapter Installation Guide
69
Speed/Duplex (Copper)
The Speed/Duplex (Copper) property sets the link speed and duplex mode
for the twisted pair copper interface.
To change the Speed/Duplex (Copper) property, do the following:
1. Access the Advanced Properties.
See “Accessing Advanced Properties” on page 60.
2. Select Speed/Duplex (Copper) in the Property box.
The Speed/Duplex (Copper) page is displayed as shown in Figure 37.
Figure 37. Speed/Duplex (Copper) Page
3. Select one of the following options:
 (0) Auto Negotiate — The speed and duplex mode are
automatically negotiated. This is the default setting.
 (1) 100Mb/Half Duplex
 (2) 100Mb/Full Duplex
 (3) 10Mb/Half Duplex
 (4) 10Mb/Full Duplex
4. Click OK.
