32
• C-WIDTH : This sets the width of the center image. The higher the setting, the
less sound comes from the center speaker.
• DIMENSION : Incrementally adjusts the sound field (DSP)from the front or surround.
• PANORAMA : This mode extends the front stereo image to include the surround
speakers for an exciting "wraparound" effect with side wall imaging.
Dolby Pro Logic llx effect
Setting Dolby Pro Logic llx effect
This function works only in Dolby PRO LOGIC IIx MUSIC Mode.
Press SETUP/MENU button, and then press the ENTER
button.
• “SETUP MODE” appears on the display and goes into Setup Mode.
Press button to select the “ MODE”,
and then press the ENTER button.
Press button.
• Each time you press this button,
C-WIDTH
➝ DIMENSION ➝
PANORAMA will be selected in turn.
Press …† button to set the
Dolby Pro Logic llx effect you
want.
To exit setup mode
• Wait for about 5 seconds or press SETUP/MENU button.
“SETUP OFF” appears on the display and Setup Mode is exited.
1
2
3
4
1 Press MODE button to select ‘MUSIC’ Mode.
2 Press EFFECT button.
• Each time you press this button, C-WIDTH ➝ DIMENSION ➝ PANORAMA
will be selected in turn.
3 Press …† button to select Dolby Pro Logic IIx effect you want.
• C-WIDTH : You can set from 0 to 7.
• DIMENSION : You can set from -7 to +7.
• PANORAMA : You can set it ON or OFF.
Using the EFFECT button
