28
Test tone
Use the test tone check the speaker connection status or level.
√
To automatically output test tone
Press SETUP/MENU button, and then press the ENTER
button.
• “SETUP MODE” appears on the display and the unit goes into Setup Mode.
Press button to select the “TEST-T AUTO”,
and then press the ENTER button.
• Test signal will be automatically output as follows; F.L ➝ CEN ➝ F.R ➝
S.R ➝ SBR ➝ SBL ➝ S.L ➝ S.W .
• During test signal output, press …† button to adjust the individual speaker
output level from -10 to +10 dB by 1 step.
1
2
To stop test tone
• Press SETUP/MENU button once time.
“SETUP OFF” appears on the display and test tone stops.
Press TEST TONE button.
• Test signal will be automatically output as follows; F.L
➝ CEN ➝ F.R ➝ S.R ➝
SBR ➝ SBL ➝ S.L ➝ S.W.
• During test tone output, press …† button to adjust the speaker output level from
-10 to +10 dB by 1 step.
Using the Test Tone button
