30
• F.L (front left) : -10 ~ +10dB
• CEN (center) : -10 ~ +10dB
• F.R (front right) : -10 ~ +10dB
• S.R (surround right) : -10 ~ +10dB
• SBR (surround back right) : -10 ~ +10dB
• SBL (surround back left) : -10 ~ +10dB
• S.L (surround left) : -10 ~ +10dB
• S.W (subwoofer) : -10 ~ +10dB
Setting Speaker Level
Setting speaker level
You can set the balance and level of speakers.
√
Press SETUP/MENU button, and then press the ENTER
button.
• “SETUP MODE” appears on the display and goes into Setup Mode.
Press button to select the “LEVEL SETUP”, and then
press the ENTER button.
Press button to select the speaker you want.
• Each time you press button, F.L ➝ CEN ➝ F.R ➝ S.R ➝ SBR ➝ SBL
➝ S.L ➝ S.W will be selected in turn.
Press …† button to set the speaker mode.
• You can adjust it from -10 to +10dB by 1 step.
• The sound gets quieter at -10dB and louder at +10dB.
1
2
3
4
To exit setup mode
• Wait for about 5 seconds or press SETUP/MENU button.
“SETUP OFF” appears on the display and Setup Mode is exited.
1 Press SPK LEVEL button to select the speaker you want.
• Each time you press this button, F.L
➝ CEN ➝ F.R ➝ S.R ➝ SBR ➝ SBL ➝ S.L
➝ S.W ➝ SPK LVL OFF will be selected in turn.
2 Press …† button to set the speaker level you want.
• You can adjust it from -10 to +10dB by 1 step.
• The sound gets quieter at -10dB and louder at +10dB.
Using the SPK LEVEL button
