English - 5
Remote Control
You can use the remote control up to a distance of about 23 feet from the TV. When using the remote control, always point it
directly at the TV. You can also use your remote control to operate your VCR, Cable box, DVD player, or Set-Top Box.
➢  This is a special remote control for the visually impaired, and has Braille points on the POWER, Channel, Volume, STOP and
PLAY/PAUSE buttons.
 The performance of the remote control may be affected by bright light.
1 POWER
Turns the TV on and off.
2 Numeric Buttons
Press to directly select a channel.
3 –
Press to select additional channels
being broadcast by the same station.
For example, to select channel “54-
3”, press “54”, then press “–” and “3”.
4 CH LIST
Used to display Channel Lists on the
screen.
5 ANTENNA
Press to select “Air” or “Cable”
6 VCR/DVD Functions
- Rewind
- Stop
- Play/Pause
- Fast Forward
7 MUTE
Press to temporarily cut off the sound.
8 VOL +, VOL –
Press to increase or decrease the
volume.
9 MENU
Displays the main on-screen menu.
0 UP▲/DOWN▼/LEFT◄/RIGHT►/
ENTER
Use to select on-screen menu items
and change menu values.
! RETURN
Returns to the previous menu.
@ P.MODE
Press to select the picture mode.
# S.MODE
Press to select the sound mode.
$ AUTO PROG.
Press to automatically store selected
Air/Cable channels.
% ADD/DEL
Use to store and delete channels
to/from memory.
^ SET
Sets the remote to control your TV,
VCR, Cable, DVD, or Set-Top Box.
& TV, DVD, STB, CABLE, VCR
Press to operate your TV, DVD, STB,
CABLE (box), or VCR.
* SOURCE
Press to display all of the available
video sources.
(
Press to activate the backlight of
the VOL, CH, and the active source
button (TV, DVD, CABLE, STB, VCR)
on the remote control.
) PRE-CH
Tunes to the previous channel.
a FAV.CH
Press to switch to your favorite
channels.
b SLEEP
Press to select a preset time interval
for automatic shut off.
c CH , CH
Press to change channels.
d EXIT
Press to exit from the menu.
e INFO
Press to display information on the
TV screen.
f CAPTION
Controls the caption decoder.
g Color buttons
Press to add or delete channels
and to store channels to the favorite
channel list in the “Channel List”
menu. (Refer to pages 15~16)
h S.STRENGTH
Press to check the digital signal
strength.
i P.SIZE
Press to change the screen size.
j SRS
Selects SRS TruSurround XT mode.
k MTS
Press to choose Stereo, Mono or
Separate Audio Program (SAP
broadcast).
l RESET
When your remote control does not
work, change the batteries and press
the RESET button for 2-3 seconds
before use.
Installing Batteries in the Remote Control
1 Lift the cover at the back of the remote control upward as shown in the figure.
2 Install two AAA size batteries.
➢  Make sure to match the + and – ends of the batteries with the diagram inside the
compartment.
 Do not mix battery types, i.e. alkaline and manganese.
3 Replace the cover.
➢ Remove the batteries and store them in a cool and dry place if you won’t be using the
remote control for a long time. The remote control can be used up to about 23 feet from
the TV. (Assuming typical TV usage, the batteries last for about one year.)
