Introduction_ 15
1.
introduction
These are the main components of your machine:
This chapter includes:
• Machine overview
• Control panel overview
• Understanding the status LED
• Turning the machine on
• Connecting a printer cable
• Adjusting angle of the control panel
• Introducing the display screen and useful buttons
• Understanding the pop-up keyboard
• Using the manual stapler
• Using the pen and paper clip holder
• Viewing the animation for trouble shooting
Machine overview
Front view 1
1 Duplex automatic document feeder cover 8 Optional dual cassette feeder (tray 3, tray 4) a
2 Duplex automatic document feeder width guides 9 Standard tray (tray 1, tray 2)
3 Duplex automatic document feeder input tray 10 Front door
4 Duplex automatic document feeder output tray 11 Front door handle
