Samsung SF-5100PI-XAA - Manual (Page 86)

4.7 Using AnyPage Lite
11. To save the recognition results, click button on the toolbar.
The AnyPage Lite system can save the recognition results in the
following formats; TXT, RTF, HTML. The RTF format allows you to save
not only text, but also information about the page layout, pictures and
tables.
You can send the recognized text by E-mail or fax. To do this, select
MailThru or FaxThru from the Tools menu.
12. To exit, close the AnyPage Lite window. You are prompted to save the
batch for further work. Select Yes or No . If you save the batch, the
recognition results of each page are saved into a special file with the
APF (AnyPage Lite Format) extension.
To analyse, then recognize automatically
Click button on the toolbar, and select the file you want to recognize
from the open dialogue box.
That’s all you need to do. The system automatically starts analyzing the
image locating texts, pictures, and tables, and then finally recognizes the
texts and tables. The recognized results will be displayed in the Text
window.
To analyse manually, then start recognize
The AnyPage Lite system can successfully analyse pages with a compound
text or table layout. However, when the table you want to recognize does
not have horizontal or vertical lines or when it has irregular structure
(configuration of the cells merged vertically and horizontally), you’ll need
to analyse the table manually before starting recognition.
A table requiring manual analysis
• Modem Speed 14400, 12000, 9600, 7200
• Transmission Speed 6 sec.
• Resolution
Horizontal 11.8 lines/mm
Vertical Standard: 3.85 lines/mm
Fine: 7.7 lines/mm
• Printing Speed 8 ppm
• Scanning Speed Standard: 4.5 sec.
Fine: 6 sec.
Using AnyPage Lite
