14
Side Views
The following items can be found on the sides of your device.
1. Volume Key: From a
Home screen, press
to adjust Master
Volume. During
music playback,
press to adjust
volume.
2. Power/Lock Key:
Press and hold to
turn the device on
or off. Press to lock
the device or to wake the screen for unlocking.
Back and Bottom Views
The following items can be found on the back and bottom of your
device.
1. Camera Lens: Used to take photos or record videos.
2. 3.5mm Headset Jack: Plug in
for headphones, which also
serve as an antenna. For
more information, refer to
“FM Radio” on page 70.
3. External Speakers: Used for
music or video playback,
notification tones, and for
other sounds.
4. Memory Card Slot: Remove
the cover to install a
memory card for storage of
files. For more information,
refer to “Installing the
Memory Card” on page 5.
5. Microphone: Used for voice
recording or video chat.
1
2
5
1
3
4 2 3
