6
American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781
Upper Front Panel Assembly (For Cold Rolled Steel [CRS] Door)
Illus. No. Part No. Qty. Description
1 800635* 1 Right Hand Upper Front Panel Assembly
(includes illus. nos. 1, 2, and 3)
850974* 1 Left Hand Upper Front Panel Assembly
(includes illus. nos. 1, 2, and 3)
884010 1 Right Hand Stainless Steel Upper Front Panel Assembly
(includes illus. nos. 1, 2, and 3)
2 154215 2 1/4” Pop Rivet
3 170330 1 Friction Door Latch
4 112350 1 ADC Logo ONLY
870011 1 Logo Double Tape Kit
5 150313 8 #10-16 x 1/2” TORX + Screw
6 -------- -- Main Door Hinge
(refer to Main Door “Steel” Assembly on page 8)
* Specify color when ordering.
