Motor Mount Assembly
(continued)
Illus. No. Part No. Qty. Description
8 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
9 153002 4 5/16” Lock Washer
10 153001 4 5/16” Flat Washer
11 154000 4 5/16-18 Tinnerman Nut
12 181049 1 1/2 hp 100-230v 1ø 50/60 Motor with Plug
13 150501 4 5/16-18 x 3/4” Hex Head Machine Bolt
14 153002 4 5/16” Lock Washer
15 153001 4 5/16” Flat Washer
16 153001 * 5/16” Flat Washer
17 101131 1 1/2” x 2-1/4” Motor Pulley (for use on 1ø, 60 Hz models Only)
101133 1 5/8” x 2-1/4” Motor Pulley (for use on 3ø, 60 Hz models Only)
101125 1 1/2” x 2-1/2” Motor Pulley (for use on 1ø, 50 Hz models Only)
101130 1 5/8” x 2-1/2” Motor Pulley (for use on 3ø, 50 Hz models Only)
18 100113 1 4L-400 V-Belt (to idler) for 60 Hz Models ONLY
100115 1 4L-410 V-Belt (to idler) for 50 Hz Models ONLY
19 122701 8 Socket Terminal
20 137030 1 8-Pin Housing
122801 1 Pin/Socket Extraction Tool (not illustrated)
21 826316 1 120v 1ø Motor Harness with Plug
826317 1 230v 1ø Motor Harness with Plug
22 100007** 1 1/2 hp 208/230/380/460v 3ø 50/60 Hz Motor
23 120200 1 3/8” x 90º Connector
24 100723 1 1/8” x 1/8” x 1-3/8” Key (for use on 1ø models Only)
100701 1 3/16” x 3/16” x 1” Key (for use on 3ø models Only)
* As required.
** Specify voltage when ordering.
