Locking Coin Control Door Assembly
Illus. No. Part No. Qty. Description
1 884136* 1 Coin Control Door Assembly
(includes illus. nos. 1 and 6)
884207 1 Stainless Steel Coin Control Assembly
(includes illus. nos. 1 and 6)
2 160140 1 ACE ® Key XX4451
3 154011 4 #10-32 Multi-Thread U-Nut
4 150314 4 #10-32 x 1/2” TORX BTN Head Machine Screw
5 160040 1 Control Door Lock
6 117604 3 1/8” x 3/8” Sponge Tape (sold by the foot)
* Specify color when ordering.
