Phase (3ø) motor, electrical relay panel assembly – American Dryer Corp. AD-236 User Manual
Page 29
27
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
1
136008
2
Fuse Holder
2
132495
1
Three Pole 24 VAC Motor Contactor
3
855256
1
Transformer Assembly (208-240V)
4
121010
1
Terminal Lug
5
315293
1
Rear Wire Box Back Plate
6
315294
1
Phase 7 Rear Wire Box Body
7
315300
1
Rear Wiring Box Cover
8
353142*
1
Power Block Mounting Bracket
9
152001*
2
3/8” Hex Nut
10
121300*
2
Open/Closed Bushing
11
153012*
2
Star Washer
12
153528*
4
1/2” Clinch Stud
13
120701*
1
4-Position Terminal Block
14
151000*
2
Pal Nut
15
150301
12
7/16” Phillips TEK Screw
16
150300
4
1/2” Hex TEK Screw
17
150009*
2
1-1/2” Phillips Machine Screw
18
120910
1
Green Ground Screw
19
136057
2
1/2-amp Slo-Blo Fuse
20
120701*
1
4-Position Terminal Block
21
150009*
2
#6-32 x 1-1/2” Phillips Machine Screw
22
153012*
2
Star Washer
23
152001*
2
3/8” Hex Nut
24
353142*
1
Power Block Mounting Bracket
25
121300*
2
Open/Closed Bushing
26
151000*
2
#6-32 Pal Nut
*
Parts for top pocket electric box only.
3-Phase (3ø) Motor, Electrical Relay Panel Assembly
