Direct Spark Ignition (DSI) Gas Valve/Burner Assembly
Illus. No. Part No. Qty. Description
1 824142 1 Gas Valve/Burner Tube Mounting Plate ONLY
809313* 1 Natural Gas - Gas Valve/Burner Assembly Complete Less Orifice
(includes illus. nos. 1 and 3 through 18)
809314* 1 Liquid Propane (L.P.) Gas Valve/Burner Assembly Complete Less Orifice
(includes illus. nos. 1 and 3 through 18)
882396** 1 Liquid Propane (L.P.) Conversion Kit with Orifice
2 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
3 141317 1 1/2” Union Elbow
4 318650 1 Notched Pipe Bracket
5 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
6 128927 1 1/2” 24 VAC (natural gas) Gas Valve
880960 1 1/2” 24 VAC (liquid propane [L.P.]) Gas Valve
7 318650 1 Notched Pipe Bracket
8 150301 2 #8-18 x 7/16” Phillips Pan Head TEK Screw
9 141235 1 1/2” Single Port Manifold
10 140829 1 #18 Burner Orifice (natural gas Only)
140814 1 #38 Burner Orifice (liquid propane [L.P.] gas Only)
11 153012 1 #8 Internal Star Washer
12 152001 1 #8-32 x 3/8” Hex Nut
13 141131 1 Up-Shot Burner Tube
(includes illus. no. 15)
14 318009 1 Burner Tube Bracket
15 --------*** 1 Flame Spreader
16 150315 2 #6 x 3/8” Phillips Pan Head Machine Screw
17 128917 1 Spark Electrode with High Voltage (HV) Wire
18 128918 1 Flame Sensor Probe
19 121028 1 1/4” Insulated Terminal
20 132607 2 #18 Gauge Red Silicone Wire
21 121028 1 1/4” Insulated Terminal
22 128935 1 Direct Spark Ignition (DSI) Module
23 152013 2 #6-32 Hex Nut
24 824131 1 Direct Spark Ignition (DSI) Module Mounting Bracket
* Burner orifice is not included and must be ordered separately.
** Consult factory for elevations over 2,000 feet.
*** Not sold separately.
