American Dryer Corp. AD-236 - Manual (Page 19)

17
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 880203 1 1-3/8” Flange Bearing
2 153005 4 3/8” Lock Washer
3 152005 4 3/8-16 Hex Nut
4 800981 1 Pillow Block Bearing Assembly Complete
(includes illus. nos. 4 through 15 and 20)
800980 1 Pillow Block Bearing Support ONLY
5 880779 1 1-3/8” Pillow Block Bearing
(includes illus. nos. 5, 10, and 15)
6 150601 2 3/8-16 x 2” Hex Bolt
7 153004 8 3/8” Flat Washer
8 153005 2 3/8” Lock Washer
9 152005 2 3/8-16 Hex Nut
10 154321 2 5/16-24 x 3/8” Black Setscrew
11 152004 4 5/16-18 Hex Nut
12 150621 2 5/16-18 x 1-1/2” Tap Bolt
13 153002 4 5/16” Lock Washer
14 150501 4 5/16-18 x 3/4” Tap Bolt
15 102120 1 Sintered 8 Magnet
16 822735 1 Rotational Sensor Assembly
17 100713 1 1/4” x 1/4” x 7/8” Key
18 101100 1 18” Pulley
19 100111 1 5L-650 V-Belt (to idler assembly)
20 150610 2 5/16-18 x 1-1/2” Allen Setscrew
Basket (Tumbler) Bearing Assembly
