Maestro, Installation, Wa ll – Maximum Wireless Maestro User Manual
Page 6

MAESTRO
INSTALLATION
WIRELESS
30 Barnet Boulevard
New Bedford, MA 02745
(508) 995-2200
Page 6
CABLE-HOLE
CABLES
SCREW
WOOD
PANEL
WA
LL
15
SCREW
RECEIVER
12 VOLT
POWER
SUPPLY
Mount the brass instrument meter directly over the cable hole that is also used
to route power to the instrument. For the cleanest installation, we recommend
making a hole in the wall large enough to insert the wireless receiver. We also
recommend mounting the brass meter to one of our pre-drilled mounting panels.
HOLE
