A-6 Curtis 1268 Manual, Rev. D
APPENDIX A: EMC & ESD DESIGN CONSIDERATIONS
REV BRAKE MAP % of Main C/L at midpoint of reverse brake map.
REV BRK START Vehicle speed at start of reverse brake map.
REV BRAKE END Vehicle speed at end of reverse brake map.
M2 FWD SPEED Maximum forward speed in Mode 2.
M2 ACCEL Forward acceleration rate in Mode 2.
M2 DECEL Forward deceleration rate in Mode 2.
M2 BRAKE MIN % of Main C/L at start of brake map, Mode 2.
M2 BRAKE MAX % of Main C/L at end of brake map, Mode 2.
M2 BRAKE MAP % of Main C/L at midpoint of brake map, Mode 2.
M2 BRAKE START Vehicle speed at start of brake map, Mode 2.
M2 BRAKE END Vehicle speed at end of brake map, Mode 2.
OVERVOLTAGE Threshold above which regen current decreases.
LOW VOLTAGE Threshold below which drive current decreases.
THROTTLE MAP Midpoint value that shapes the throttle map.
THROTTLE 0% Voltage at which throttle command begins.
THROTTLE 100% Voltage at which throttle command is maxed out.
THROT FAULT LO Voltage under which a throttle fault occurs.
THROT FAULT HI Voltage over which a throttle fault occurs.
M1 FWD FLD MIN Minimum field current, forward direction, Mode 1.
REV FIELD MIN Minimum field current, reverse direction.
M2 FWD FLD MIN Minimum field current, forward direction, Mode 1.
FLD MAP START Positive armature current at which field map begins.
FIELD RAMP Midpoint value that shapes the field map.
FIELD MAX Maximum field current during drive.
FIELD MAP END Positive armature current at which field map ends.
NEG FLD MAP ST Neg. armature current at which neg. field map begins.
NEG FIELD RAMP Midpoint value that shapes the negative field map.
NEG FIELD MAX Maximum field current during regen braking.
NEG FLD MAP EN Neg. armature current at which neg. field map ends.
WALKAWAY C/L Field current during WalkAway ™ operation.
KSI SRO ENABLE Keyswitch must be off at power-up (yes/no).
DRV OVRCURR DIS Driver overcurrent detection disable (on/off).
FIELD DIR SWAP Swaps polarity of motor field output (on/off).
Program Menu, cont’d
APPENDIX B: PROGRAMMING DEVICES & MENUS
B-3
