Appendix A. Probe Assembly
FIGURE A-1. Finished EnviroSMART
TM
Assembly
Figure A-1 shows a finished three-sensor probe. Your probe may require more
or less than three sensors at different spacing.
FIGURE A-2. Probe Rod Top
Remove the probe rod from the access tube by removing the plug on one end of
the tube. The plug can be removed by shaking the tube vertically such that the
rod internally hammers on the plug and eventually dislodges it. Identify the
“top” as indicated in Figure A-2.
FIGURE A-3. Location of Large Handle Screws
