Page 19
Section 2. CM6/CM10 Tripod Installation
FIGURE 2-5. Tripod Ground Connections
2.5 CM10 Guy Kit Installation
The CM10 Guy Kit is an option when purchasing the CM10 Tripod or CM10K
Tripod Kit. It can be installed to improve the CM10 Tripod wind load rating.
Table 2-3 lists items in the CM10 Guy Kit.
TABLE 2-3. CM10 Guy Kit Parts
Item # CSI Part # Description
Quantity
G1 10845 Wire
Rope 3
G2 10846 Turnbuckle
3
G3 10848 Top
Plate 1
G4 10849 Bottom
Plate
3
G5 6131
Thimble 6
G6 6132
U-Bolt
12
Install the guy kit as shown in Figure 2-6.
2-7
