1 Getting Started
Figure 1: GLK19264-7T-1U
The GLK19264-7T-1U is an intelligent graphic LCD display designed to decrease development time by
providing an instant solution to any project. With the ability to communicate via serial RS-232/TTL and
I
2 C protocols, the versatile GLK19264-7T-1U can be used with virtually any controller. The GLK19264-
7T-1U-USB has the ability to communicate via USB. The ease of use of these displays is further enhanced
by an intuitive command structure to allow display settings such as backlight brightness, contrast and baud
rate to be software controlled. Additionally, text and fonts may be uploaded to the display and stored in the
on board memory.
1.1 Display Options Available
Both the (Non-USB) GLK19264-7T-1U and the (USB) GLK19264-7T-1U-USB modules come in two
colour options, grey text with white background and white text with blue background. Temperature options
are also available to allow you to select the display which will best fit your project needs.
Figure 2: GLK19264-7T-1U Options
1.2 Accessories
NOTE Matrix Orbital provides all the interface accessories needed to get your display
up and running. You will find these accessories and others on our e-commerce website
at http://www.matrixorbital.com. To contact a sales associate see Section 16.6 for contact
information.
