Description This command will allow you to reassign the key codes that correspond
to the key presses on the matrix style key pad. The first 9 bytes that are
transmitted will be used for the key down codes and the next 9 bytes
that are transmitted will be used for the key up codes.
For the above diagrams the mapping is as follows:
Row 1, Column 1 = byte 1
R1, C2 = byte 2
R1, C3 = byte 3
R2, C1 = byte 4
R2, C2 = byte 5
R2, C3 = byte 6
R3, C1 = byte7
R3, C2 = byte 8
R3, C3 = byte 9
NOTE * not mapped to a physical key on the attached keypad.
Remembered Always
11 Display Functions
11.1 Introduction
The GLK19264-7T-1U employs software controlled display settings, which allow for control over, clear-
ing the screen, changing the brightness and contrast or setting timers for turning it on or off. The combination
of these allow you complete software control over your display’s appearance.
11.2 Clear Screen
